Understanding the X.509 Certificate Hierarchy and Revocation

Public Key Infrastructure (PKI) is the backbone of secure communication on the internet. At the heart of PKI lies the X.509 certificate standard, which defines how digital certificates are issued, validated, and revoked. This post explains the X.509 hierarchy, how certificate chains work, and why certificate revocation is critical.

X.509 Certificate Hierarchy

X.509 uses a hierarchical trust model based on Certificate Authorities (CAs).

Levels in the Hierarchy:

Root CA — The topmost trusted authority
Intermediate CAs — Certified by higher-level CAs to reduce risk
End Entities — Users, servers, or applications that receive certificates

Trust Flow:

Trust flows downward (certificates are issued)
Verification flows upward (signatures are checked)

Hierarchical Structure:

Root CA (self-signed)
    ↓
Intermediate CA (signed by Root)
    ↓
End Entity Certificate (signed by Intermediate)

Key Properties:

Root CA is self-signed — Trust anchor for the entire hierarchy
Intermediate CAs reduce risk — If compromised, only affects their subtree
End entities are leaves — Cannot issue certificates to others
Scalable trust model — Works for internet-scale systems

Certificate Signing and Notation

In certificate chains, the notation:

X << Y >>

means Y's certificate is signed by X (X is the issuer, Y is the subject).

Examples:

X << A >> → A's certificate is signed by CA X
Z << B >> → B's certificate is signed by CA Z

Reading the Notation:

X << Y >> reads as "X signs Y"
Left side (X) = Issuer (signer)
Right side (Y) = Subject (entity being certified)

Certificate Chain Example:

Root_CA << Intermediate_CA >>
Intermediate_CA << Server_Certificate >>

This means:

Root CA signs Intermediate CA's certificate
Intermediate CA signs Server Certificate

Complete Chain:

Root_CA << Intermediate_CA << Server_Certificate >>

Certificate Chain Validation

When one entity wants to trust another, it validates a certificate chain.

Example: A Communicating with B

Explanation of the X.509 hierarchy in the diagram (concise):

What the diagram shows:

It is a Public Key Infrastructure (PKI) trust tree.

Each circle (U, V, W, X, Y, Z, A, B, C) represents an entity (CA or end user).
Upper nodes are Certificate Authorities (CAs), lower nodes are end entities.
Trust flows downward, verification flows upward.

Meaning of the notation X << Y >>:

X << Y >> means:

Y's certificate is signed by X
(or X is the issuer, Y is the subject).

Example:

X << A >> → A's certificate is signed by X
V << W >> → W's certificate is signed by V

Certificate chains (paths):

A → B (A wants to trust B):

A does not directly trust B, so it builds a certificate chain:

X << W >> W << V >> V << Y >> Y << Z >> Z << B >>

Meaning:

B is signed by Z
Z is signed by Y
Y is signed by V
V is signed by W
W is signed by X
X is trusted by A

So trust flows upward until a common trusted CA is reached.

B → A (reverse direction):

Similarly:

Z << Y >> Y << V >> V << W >> W << X >> X << A >>

Same idea, just reversed.

Key idea:

End entities don't trust each other directly
They trust CAs
Verification works by following certificate signatures up the hierarchy
If the chain ends at a trusted root, the certificate is accepted

Why This Works:

This mechanism allows scalable trust without every entity knowing every other entity.

Real-World Example: HTTPS

Browser receives website's certificate
Browser follows chain: Server → Intermediate CA → Root CA
Browser checks if Root CA is in trusted store
If valid, browser trusts website's certificate

Certificate Revocation

Certificates are not valid forever, and sometimes they must be invalidated before their expiry date.

Validity Period

Every certificate has:

Start date — When certificate becomes valid
End date — When certificate expires

Outside this period, the certificate is automatically invalid.

Example:

Certificate for: example.com
Valid from: 2026-01-01
Valid to: 2026-04-01

After April 1, 2026, the certificate is automatically invalid, even if not revoked.

Why Revoke a Certificate Early?

A certificate may need to be revoked if:

The user's private key is compromised
- Attacker gains access to private key
- Certificate can no longer be trusted
- Must revoke immediately to prevent impersonation
The user is no longer certified by the CA
- User leaves organization
- Domain ownership changes
- Certification relationship ends
The CA's own certificate is compromised
- CA's private key is compromised
- All certificates issued by that CA must be revoked
- Requires reissuing certificates under new CA key

In these cases, continuing to trust the certificate would be unsafe.

Certificate Revocation List (CRL)

To handle revocation, CAs maintain a list called the Certificate Revocation List (CRL).

What Is a CRL?

The CRL contains serial numbers of revoked certificates
It is digitally signed by the CA
Updated and published periodically

CRL Contents:

Serial numbers of revoked certificates
Revocation date for each certificate
Reason for revocation (optional)
CRL version and update information

CRL Format:

Certificate Revocation List
Issued by: CA_Name
Valid until: 2026-01-15 12:00:00
Last updated: 2026-01-08 12:00:00

Revoked Certificates:
Serial Number: 0x1234ABCD, Revoked: 2026-01-05, Reason: Key compromise
Serial Number: 0x5678EFGH, Revoked: 2026-01-07, Reason: Cessation of operation
...

Certificate Checking

Before trusting a certificate, users (or applications):

Verify the certificate chain
- Check signatures up to root CA
- Confirm chain is valid
Check the CA's CRL to ensure the certificate has not been revoked
- Retrieve current CRL from CA
- Check if certificate serial number appears in CRL
- If found, certificate is revoked

Result:

If the certificate appears in the CRL, it must be rejected—even if it has not expired.

Why This Matters:

Certificate may still be within validity period
But has been explicitly revoked
Must not be trusted regardless of expiry date
