RC4 Stream Cipher Explained: Algorithm and Steps

RC4 (Rivest Cipher 4) is one of the most well-known stream ciphers in the history of cryptography. Although it is deprecated today, RC4 is still widely taught because it clearly demonstrates how stream ciphers, keystream generation, and XOR-based encryption work.

This article explains RC4 from the ground up, including:

What RC4 is
Its internal algorithms (KSA & PRGA)
Step-by-step working

What Is RC4?

RC4 is a symmetric-key stream cipher designed by Ron Rivest in 1987.

Key Characteristics:

Stream cipher → encrypts data byte-by-byte
Symmetric → same key for encryption and decryption
Uses XOR to combine plaintext with a keystream

Core Formula

Encryption:

C_i = P_i ⊕ K_i

Decryption:

P_i = C_i ⊕ K_i

Where:

P_i = plaintext byte
K_i = keystream byte
C_i = ciphertext byte

Why XOR for Decryption? Because XOR is reversible: (A ⊕ B) ⊕ B = A

Encryption: C = P ⊕ K
Decryption: P = C ⊕ K = (P ⊕ K) ⊕ K = P

High-Level Idea of RC4

RC4 works in two main phases:

1. KSA (Key Scheduling Algorithm) → Initializes and scrambles an internal array using the key

2. PRGA (Pseudo-Random Generation Algorithm) → Generates a keystream byte-by-byte

That keystream is XORed with plaintext to encrypt (or decrypt).

Process Flow:

Secret Key → KSA → Scrambled S Array → PRGA → Keystream → XOR with Plaintext → Ciphertext

Internal Data Structures

RC4 uses:

S array: A permutation of numbers 0–255 (256 bytes)

Initially: S[0] = 0, S[1] = 1, ..., S[255] = 255
After KSA: Permuted based on the key

Key: Variable length (typically 40–256 bits)

Two indices: i and j

Used to select and swap elements in S array

Step 1: Key Scheduling Algorithm (KSA)

Purpose

To initialize and shuffle the array S[0…255] based on the secret key.

Steps

Initialize S[i] = i for i = 0…255
Use the key to permute S through swapping operations

Pseudocode (KSA)

for i = 0 to 255:
    S[i] = i

j = 0
for i = 0 to 255:
    j = (j + S[i] + key[i mod key_length]) mod 256
    swap(S[i], S[j])

How KSA Works

Initialization:

Set S to identity permutation: [0, 1, 2, ..., 255]

Permutation:

For each index i from 0 to 255:
- Calculate j using current S[i] and key byte
- Swap S[i] and S[j]
- This shuffles the array in a key-dependent way

After KSA:

S becomes a key-dependent permutation
This array is the internal state of RC4
Same key always produces the same initial S state

Step 2: Pseudo-Random Generation Algorithm (PRGA)

Purpose

To generate the keystream, one byte at a time.

Steps

Update indices i and j
Swap elements in S
Output one keystream byte

Pseudocode (PRGA)

i = 0
j = 0
while (data to encrypt):
    i = (i + 1) mod 256
    j = (j + S[i]) mod 256
    swap(S[i], S[j])
    t = (S[i] + S[j]) mod 256
    K = S[t]
    output K

How PRGA Works

For each byte needed:

Increment i: i = (i + 1) mod 256
Update j: j = (j + S[i]) mod 256
Swap: Exchange S[i] and S[j]
Compute index: t = (S[i] + S[j]) mod 256
Output keystream byte: K = S[t]

Each iteration produces one keystream byte.

Important: The state array S is modified during PRGA, so each keystream byte depends on the previous state.

What Are We Ensuring? (Key Guarantees)

Every keystream byte depends on the entire past state:

i increases sequentially — Simple counter that cycles through S array
j accumulates values from S — Uses current S state to determine next j
S is continuously mutated via swaps — State changes with each iteration

📌 Guarantee:

The current keystream byte depends on all previous swaps, not just the key.

What This Means:

First keystream byte depends on:
- Initial S state (from KSA)
- First swap in PRGA
Second keystream byte depends on:
- Initial S state (from KSA)
- First swap
- Second swap
N-th keystream byte depends on:
- Initial S state (from KSA)
- All previous N swaps in PRGA

This prevents simple prediction.

❌ You cannot predict the next keystream byte without knowing the entire current state
❌ You cannot compute keystream bytes independently
❌ Each byte requires all previous computation
✅ Creates pseudo-random appearance
✅ Makes cryptanalysis more difficult

Why Generate a Keystream? (Key vs. Keystream)

What happens if we use the key directly? (BAD)

Problem: Key Repetition

If we simply repeat the key as the keystream:

Plaintext = [10, 20, 30, 40, 50, 60]
Key = [3, 1, 4]

Key repeated as keystream:
Keystream = [3, 1, 4, 3, 1, 4]  ❌ Pattern visible!

Issues:

⚠️ Visible repetition in the keystream
⚠️ Short key reused multiple times
⚠️ Patterns make cryptanalysis easier
⚠️ Vulnerable to known-plaintext attacks

Now: Generate a keystream from the key (GOOD)

Instead of repeating the key, we use an algorithm:

Key → Algorithm (KSA + PRGA) → Keystream

Example:

Same key
Key = [3, 1, 4]

Generated keystream (example output)
Keystream = [91, 203, 17, 88, 240, 61]  ✅ No visible repetition

Benefits:

✅ No visible repetition — appears random
✅ Long keystream from short key
✅ Appears unpredictable (statistically)

Critical Warning:

Same key produces the same keystream
If the same key is used for multiple messages, the keystream repeats
This breaks security: C₁ ⊕ C₂ = P₁ ⊕ P₂ (key cancels out)
Always use unique keys or initialization vectors (IVs)

Step 3: Encryption

Encryption is simple:

Ciphertext = Plaintext XOR Keystream

RC4 Pseudocode (All-in-One)

Complete RC4 Algorithm:

RC4(key K, plaintext P): //Key = [1, 2, 3], Plaintext = [10, 20, 30]

// ---------- KSA ----------
for i = 0 to 255:
    S[i] = i

j = 0
for i = 0 to 255:
    j = (j + S[i] + K[i mod keylen]) mod 256
    swap(S[i], S[j])

// ---------- PRGA + Encryption ----------
i = 0
j = 0
for n = 0 to len(P)-1:
    i = (i + 1) mod 256
    j = (j + S[i]) mod 256
    swap(S[i], S[j])
    t = (S[i] + S[j]) mod 256
    k = S[t]
    C[n] = P[n] XOR k

return C //Ciphertext = [11, 23, 28] for keystream = [1, 3, 2]

Conclusion

RC4 Summary:

✅ RC4 uses KSA to permute the S array based on the key
✅ PRGA generates keystream bytes one at a time
✅ Encryption & decryption use XOR with keystream
✅ Same key → same keystream → same result
⚠️ Deprecated due to security vulnerabilities

While RC4 is no longer secure, studying it provides valuable insights into cryptographic design and the evolution of encryption standards. Modern alternatives like ChaCha20 and AES incorporate lessons learned from RC4's weaknesses, making them significantly more secure for real-world applications.
